3/8" Bronze pressure Gauge cock, Screwed Ends 10 MM

Product details

Product description :

The 3/8-inch Bronze Pressure Gauge Cock is a compact and reliable component designed to control the flow to pressure gauges in various industrial and commercial systems. Constructed with high-quality bronze , it ensures excellent durability, resistance to corrosion, and reliable performance under challenging conditions.

The 10mm size and precision-engineered screwed ends make it easy to install and provide a secure, leak-free connection. Ideal for accurate pressure regulation and safety in pipelines, this gauge cock is a vital addition to pressure monitoring systems.

Key Features :

🔩 Body Material: Constructed from premium Bronze, compliant with IBR 282 (a) (iv) Gr. B standards.

🛠️ Design: Includes a pressure gauge cock with coupling nut and tail pipe for precise control and easy operation.

🔗 End Connection: Features Screwed Female BSP Taper Threads (BS-21) for robust and leak-free connections.

💧 Test Pressure: Thoroughly tested to withstand up to 500 Psig (Hydraulic), ensuring durability.

⚙️ Max. Working Pressure: Capable of handling 250 Psig in steam systems for dependable performance.

🔥 Max. Working Temperature: Designed to operate safely up to 225°C, perfect for high-temperature environments.
